What’s a van type semi-trailer ?

The Van type semi-trailer series products are mainly used for the transportation of household appliances, light textile goods, coal, sand and stone and other construction materials as well as pallet goods. The box body is made of high-strength cold-rolled corrugated steel plate, with no frame structure, central distribution, various choices, large loading space, reasonable distribution inside the box, X-shaped tensioning, with the characteristics of multiple pulling, heavy load, and light weight. The box roof has closed type, push-pull opening type, open type, open tarpaulin rod type, etc. It is easy to operate and meets the diverse and personalized requirements of users. Starway van semi-trailer production technology is advanced and the workmanship is excellent.

What are the van semi-trailers?

1、Van Type Truck Trailer

2、Closed Van Trailer

3、Refrigerated Truck Trailer

4、Wing Trailer

5、Side curtain Trailer

Production Technology :

The van-type semi-trailer adopts a closed side guardrail design, which effectively reduces the lateral risk of the vehicle when driving at high speed and reduces energy consumption. The rear guard design has reasonable cart accessories for easy operation. It is modified or manufactured separately on the chassis of a van. According to the difference in its compartment, it can be divided into passenger compartment type and carriage type. The passenger compartment and the cab are generally an integral structure, such as ambulances, accommodation vehicles, environmental testing vehicles, dining vehicles, TV broadcast vehicles, etc. The carriage-type compartment and the cab are generally a split structure, such as van-type LTL transport vehicles, refrigerated insulation vehicles, etc.

Features of van type trailer :

The detailed structural form of the compartment varies according to its function.
1. In addition to the functions of ordinary compartments, the compartment of the refrigerated and insulated truck also has the functions of heat insulation and heat preservation;
2. The roof of the convertible compartment can be raised and lowered vertically to change the compartment volume to meet the loading and unloading requirements of different goods;
3. The wing-opening compartment is convenient for loading and unloading of goods and improves loading and unloading efficiency.
4. The series of vans are divided into box-type semi-trailers and second-hand chassis modified vans.
5. The body of the vehicle is made of high-quality steel and manufactured by strict production technology. The vehicle has a reasonable structure, reliable performance, easy operation and beautiful appearance.
6. The accessories are products of well-known manufacturers at home and abroad, and are purchased, repaired and used in strict accordance with the requirements of the quality system documents, ensuring the good performance of the vehicle.

The specification of STARWAY VEHICLE standard 3 axles van type semi trailer :

Brand :Starway Vehicle

Application : Food/Cargo Loading

Loading Capacity :20-100 Tons (Customer Requirement)

L*W*H :13000*2550*2400mm

Door Position : Multi-Choice

Door opening style : Multi-Choice

Box Plate Thickness : 0.9mm

OEM/ODM :Available

Tandem Style :Available

SKD/CKD Cooperation：Available

Main Beam Material : Q345/T700

Height :500mm

Axles : 2*13T/16T FUWA/BPW

Tire：11.00R20/12R22.5*8pieces

Linglong/Triangle/Double-Coin/Bridgestone

Rim:9.0/8.0*8pieces,steel/aluminum

Suspension :Mechanical/Air

Leaf Spring :90mm*13/16mm*10pieces

Landing Gears :Jost 28T two-speed

King Pin :Jost 2’’(50#)/3.5’’(90#)changeable

Tool Box : steel/aluminum

Above information are Starway vehicle standard specifications .If you want to change specifications,please let us know.Want to know more details.please contact us directly
