The modern logistics industry requires equipment that can combine strength, safety, and flexibility in order to meet diverse transportation needs. Starway’s side wall semi trailers are designed to meet these expectations, offering outstanding performance in carrying containers, bulk cargo, and general goods. With a loading capacity of 60 tons and side walls ranging from 600mm to 800mm, this trailer is a reliable partner for long-distance and heavy-duty transportation.
One of the greatest strengths of the Starway side wall trailer lies in its construction material. Unlike many standard trailers, Starway adopts high-strength steel in the production process. This choice not only increases loading capacity but also extends the overall service life of the trailer. Heavy cargo such as containers or steel coils places a lot of stress on the frame, but thanks to the robust steel structure, this trailer is able to withstand such conditions without risk of deformation or premature wear.
The structural integrity is further enhanced by Starway’s advanced welding technology. The main beam is welded using automatic arc-submerging methods, ensuring there are no weak points or interfaces between plates. This makes the main beam stronger, more reliable, and capable of supporting long-term heavy-duty operations. In addition, the reinforced down plate and gooseneck structure prevent curling, bending, or distortion, issues often seen in lower-quality trailers after extended use.
Starway pays special attention to safety features as well. The trailer is equipped with world-class components such as the German WABCO brake valve. This system greatly improves braking responsiveness, shortening the braking distance and ensuring the safety of both the trailer and the driver. For operators hauling heavy loads across highways or uneven roads, reliable braking performance is not just a convenience but a necessity.
The loading platform has also been optimized to suit multiple cargo types. The checkerplate floor increases friction, keeping bagged goods, pipes, or other bulk cargo stable during transit. At the same time, the strengthened cross beams—nine in total, with spacing less than 45cm—enhance the trailer’s ability to bear heavy loads without compromise. Combined with reinforced side beams, the entire frame ensures cargo remains secure and the trailer performs reliably over time.
Beyond technical specifications, the Starway side wall semi trailer provides practical versatility. It can transport a 40ft container or two 20ft containers without the need to dismantle side walls or frames, saving time and increasing operational efficiency. This feature makes the trailer particularly attractive to logistics companies that need equipment capable of handling both containerized and bulk cargo shipments in a single unit.
Specifications of side wall semi trailer
Dimension : 12500*2500*2800mm
Payload : 60ton
Tare weight : 8500kg
Axle :2/3/4 pcs,13T/16T ,BPW/FUWA/Starway
Suspension : Mechanical suspension / air suspension
Tire : 12R22.5 12units
Wheel rim :9.0
Kingpin : 2”/3.5”
Main beam : beam height :500mm,upper plate 14mm,lower plate 16mm,middle plate 8mm
Leaf spring : 90*13*10 layer
Landing gear : 28Ton
Platform : 3/4mm
Twist locks : 12pcs
Toolbox : 1 standard
